JET 15" Wood Working Band Saw - 3 HP, 1PH, 230V

JET SKU: 714650
JET 15" Wood Working Band Saw - 3 HP, 1PH, 230V

JET 15" Wood Working Band Saw - 3 HP, 1PH, 230V

JET SKU: 714650
Model Number: JET714650
Regular Price $2,549.99

Designed to perform, the JET 15” bandsaw delivers more re-saw capacity, greater throat depth and the horsepower you need to tackle bigger boards, create smoother edges and master the intricate cuts. The heavy-duty cast-iron fence system is built to give you the sturdiness and support you need for every project and features a micro-adjust dial for exact placement. The table is slotted and the guide post has a stress-free magnetic door on the front for efficient blade changes. Large, independently adjustable guides are tool-less to save you time on set up. The JET 15” steel frame bandsaw is engineered to build great projects through superior performance.

  • Blade tracking window provides clear view of blade during tracking.
  • Cast iron handwheels and ergonomic-designed knobs make adjustments smooth and easy.
  • Cast iron trunnion for maximum support and stability.
  • Conveniently located dual 4" dust collection ports catch dust and chips at the source.
  • Easy-to-read blade tension scale can be viewed through upper door window.
  • Heavy duty tensioning with quick release and three settings: full tension, partial tension, and full release.
  • Rigid, four-sided guide post with rack and pinion adjustment for optimum blade support.
  • Round table insert features leveling screws for precise adjustment.
  • Single knob adjustment simplifies the blade tracking process.
  • Table tilts 5° left and 45° right to accommodate a wide variety of cuts.



Stock Number JT9-714650
Band Saw Size/Wheel Diameter (In.) 14-3/4
Blade Speed (SFPM) 3100
Cutting Capacity Height (In.) 14
Dust Collection Minimum CFM Required (CFM) 400
Minimum Saw Blade Width (In.) 1/8
Model Number JWBS-15-3
Motor Amps 12
Motor Power (HP) 3
Recommended Circuit Size (Amps.) 20
Table Height from Floor (In.) 35
Table Size (L x W) (In.) 21-1/5 x 16 x 2

Operating Instructions & Parts Manual
