3/8 in. Digital Torque Wrench

Milwaukee M12 FUEL 3/8" Digital Torque Wrench w/ ONE-KEY 2465-20 + FREE XC5.0 Battery Pack M12 48-11-2450

By Milwaukee Tool
SKU 2465-20-261

Model Number: MIL246520

$899.00 - $899.00
$899.00
$899.00 - $899.00
$899.00

NEC COMPLIANT PRECISION FASTENING

For the industrial electrician, meeting NEC 110.14(D) torque requirements is no longer a manual bottleneck. The M12 FUEL™ 3/8” Digital Torque Wrench eliminates the inconsistencies of click-style wrenches by combining a high-performance motor with industry-leading digital sensors. This isn't just about speed; it is about providing a verifiable, timestamped record of every lug and terminal connection on the jobsite, ensuring your production stays ahead of schedule while maintaining 100% code compliance.

  • / MOTORIZED PRODUCTIVITY: Replaces the two-tool process by using a motor to run down fasteners before applying final digital torque, delivering 50% faster installation.
  • / UNMATCHED ACCURACY: Provides a 10-100ft-lbs torque range with a precise +/- 2% full-scale accuracy for critical electrical connections.
  • / ONE-KEY™ REPORTING: Automatically record every fastener cycle and generate professional PDF reports to provide inspectors and clients with proof of work.
  • / REDLINK PLUS™ INTELLIGENCE: Advanced electronics prevent over-torquing by cutting the motor before reaching the target torque, allowing for a final manual pull to spec.
  • / FOUR NOTIFICATION MODES: Tool alerts the user via LCD display, LED lights, audible beeps, and handle vibrations when the target torque is achieved.
TECHNICAL SPECIFICATIONS
Torque Range: 10 - 100 ft-lbs
Anvil Size: 3/8" Square Drive
Accuracy: +/- 2% CW / +/- 3% CCW
RPM: 0 - 100
Length: 23.28"
Weight: 5.5 lbs (Bare Tool)
Display Resolution: 0.1 ft-lb, 0.1 in-lb, 0.01 Nm, 0.01 kg-cm
Calibration: 1 Year or 5,000 Cycles

WHAT'S IN THE BOX

  • / (1) M12 FUEL™ 3/8” Digital Torque Wrench w/ ONE-KEY™ (2465-20)
  • / (1) Certificate of Calibration
  • / (1) Carrying Case

MAXIMIZE M12 PERFORMANCE WITH ADVANCED THERMAL MANAGEMENT AND HIGH-OUTPUT POWER

The introduction of the M12 REDLITHIUM HIGH OUTPUT XC5.0 marks a significant shift in the power-to-weight ratio for the sub-compact platform. By utilizing advanced cell technology, this pack delivers 25% more power while maintaining a significantly lower operating temperature during high-draw applications like continuous drilling or heavy-duty fastening. For professionals invested in the M12 ecosystem, this battery doesn't just provide more runtime; it unlocks the full potential of FUEL™ brushless motors, ensuring consistent torque even as the charge depletes. The chemical-resistant housing is a critical upgrade for shop environments, protecting the internal electronics from the corrosive effects of hydraulic fluids and solvents.

  • / 25% More Power: Delivers increased current to the motor, allowing M12 tools to tackle more demanding applications without stalling.
  • / Runs 25% Cooler: Optimized thermal management prevents overheating during rapid-fire tasks, extending the overall lifespan of the battery cells.
  • / Resistant Housing: Specialized plastic construction protects against common shop chemicals, oils, and greases found in automotive and industrial settings.
  • / All-Weather Performance: Engineered to deliver full power in extreme jobsite conditions down to 0°F (-18°C).
  • / System Compatibility: Seamlessly integrates with over 125+ Milwaukee M12 cordless solutions for maximum versatility across the jobsite.
TECHNICAL SPECIFICATIONS
Voltage 12V
Amp Hour 5.0 Ah
Battery Type Lithium-Ion
Weight 0.95 lbs
Dimensions (LxWxH) 3.47" x 2.62" x 4.35"
Warranty 3 Year Limited Warranty

WHAT'S IN THE BOX

(1) M12 REDLITHIUM™ HIGH OUTPUT™ XC5.0 Battery Pack (48-11-2450)
